Medical Equipment Castors

Sometimes it’s a matter of seconds – the right medication, the appropriate team, and the necessary luck. Fine, at times like this you need the reassurance that the castors from RHOMBUS are dependable. We deliver our promises: quiet operation, load-bearing capacity, safety and long product life.

Sometimes it’s a matter of seconds – the right medication, the appropriate team, and the necessary luck. Fine, at times like this you need the reassurance that the castors from RHOMBUS are dependable. We deliver our promises: quiet operation, load-bearing capacity, safety and long product life.

Fixed castor 100 mm - 300 mm, 340 kg - 1500 kg

Technical data

Diameter 200 mm
Wheel width 45 mm
Hub length 62 mm
Height 252 mm
Offset 66 mm
Wheel axle diameter 12 mm
Top plate dimensions 150 x 110 mm
Top plate hole diameter 10.5 mm
Dist. between holes 105 x 75,80 mm
Load capacity 1100 kg
Weight 6.2 kg
Reach compliant Rohs compliant

Wheel

  • Cast iron wheel with bonded-on Vulkollan tyre (Shore A 92) with two ball bearings

Technical description

  • Heavy duty welded steel rigid fork
