Furniture Castors
Moveable small and large furniture ensures flexibility and creates room for change. With furniture castors from RHOMBUS, sofabeds, audio furniture, tables, cupboards and many other furnishings can be ideally positioned, but still remain mobile.
No matter what the floor requirements, RHOMBUS has the right solution on hand, and that is in classic RHOMBUS quality, with all the characteristics to be expected of a furniture castor.
BTAB 1005 6150
Swivel castor with total brake mounted behind 100 mm - 125 mm, 180 kg - 200 kg
Technical data
| Diameter | 100 mm |
| Wheel width | 40 mm |
| Hub length | 50 mm |
| Height | 125 mm |
| Offset | 40 mm |
| Bolt hole diameter | 12 mm |
| Brake swivel radius | 134 mm |
| Load capacity | 180 kg |
| Weight | 1.45 kg |
Wheel
- Aluminium wheels with black rubber tyre (Shore A 72) with two deep groove ball bearings and steel collar bushes external diameter 15/20/25 mm to internal 8/10/12 mm. Operating temperatures from -20°C to + 80°C
Technical description
- Swivel fork of deep drawn zinc-coated steel
- Swivel bearing with double ball raceways and sealring
- with total lock brake and an extra sturdy
- plate (4 mm) and fork legs (3.5 mm)
- for even higher load capacity
