Medical Equipment Castors
Sometimes it’s a matter of seconds – the right medication, the appropriate team, and the necessary luck. Fine, at times like this you need the reassurance that the castors from RHOMBUS are dependable. We deliver our promises: quiet operation, load-bearing capacity, safety and long product life.
Sometimes it’s a matter of seconds – the right medication, the appropriate team, and the necessary luck. Fine, at times like this you need the reassurance that the castors from RHOMBUS are dependable. We deliver our promises: quiet operation, load-bearing capacity, safety and long product life.
360h 00G050x ZPC
On request
Swivel castor with total brake mounted behind 50 mm, 60 kg
Technical data
| Diameter | 50 mm |
| Tread width | 2X20 mm |
| Height | 73 mm |
| Offset | 25 mm |
| Top plate dimensions | 60x60 mm |
| Top plate hole diameter | 6 mm |
| Dist. between holes | 46x46 mm |
| Load capacity | 60 kg |
Wheel
- polyamide black
- plain bearing
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
Areas of application
- brochure display stands
- catering trolleys
- computer area
- computer furniture
- deep freezer
- display stands
- dustbins
- file carts
- food transport equipment
- housekeeping carts
- newspaper dispensers
- occasional carts
- photocopiers
- refrigerator
- restaurant areas
- sales stands
- shop fittings
- small furniture
- sport equipment
360h 33C050b ZLC
On request
Swivel castor with total brake mounted behind 50 mm - 75 mm, 60 kg - 80 kg
Technical data
| Diameter | 50 mm |
| Tread width | 2x18 mm |
| Height | 73 mm |
| Offset | 25 mm |
| Bolt hole diameter | 10 mm |
| Load capacity | 60 kg |
Wheel
- solid rubber tyre blue-grey (Shore A 80)
- plastic wheel centre grey
- metal thread guard zinc-passivated (from Ø 75 mm)
- flange bearing
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
Areas of application
- brochure display stands
- catering trolleys
- computer area
- computer furniture
- deep freezer
- display stands
- dustbins
- file carts
- food transport equipment
- housekeeping carts
- newspaper dispensers
- occasional carts
- photocopiers
- refrigerator
- restaurant areas
- sales stands
- shop fittings
- small furniture
- sport equipment
360h 33C050b ZPC
On request
Swivel castor with total brake mounted behind 50 mm - 75 mm, 60 kg - 80 kg
Technical data
| Diameter | 50 mm |
| Tread width | 2x18 mm |
| Height | 73 mm |
| Offset | 25 mm |
| Top plate dimensions | 60x60 mm |
| Top plate hole diameter | 6 mm |
| Dist. between holes | 46x46 mm |
| Load capacity | 60 kg |
Wheel
- solid rubber tyre blue-grey (Shore A 80)
- plastic wheel centre grey
- metal thread guard zinc-passivated (from Ø 75 mm)
- flange bearing
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
Areas of application
- brochure display stands
- catering trolleys
- computer area
- computer furniture
- deep freezer
- display stands
- dustbins
- file carts
- food transport equipment
- housekeeping carts
- newspaper dispensers
- occasional carts
- photocopiers
- refrigerator
- restaurant areas
- sales stands
- shop fittings
- small furniture
- sport equipment
360h 33G050b ZLC
On request
Swivel castor with total brake mounted behind 50 mm - 75 mm, 60 kg - 80 kg
Technical data
| Diameter | 50 mm |
| Tread width | 2x18 mm |
| Height | 73 mm |
| Offset | 25 mm |
| Bolt hole diameter | 10 mm |
| Load capacity | 60 kg |
Wheel
- solid rubber tyre blue-grey (Shore A 80)
- plastic wheel centre grey
- plain bearing
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
Areas of application
- brochure display stands
- catering trolleys
- computer area
- computer furniture
- deep freezer
- display stands
- dustbins
- file carts
- food transport equipment
- housekeeping carts
- newspaper dispensers
- occasional carts
- photocopiers
- refrigerator
- restaurant areas
- sales stands
- shop fittings
- small furniture
- sport equipment
360h 33G050b ZPC
On request
Swivel castor with total brake mounted behind 50 mm, 60 kg - 80 kg
Technical data
| Diameter | 50 mm |
| Tread width | 2x18 mm |
| Height | 73 mm |
| Offset | 25 mm |
| Top plate dimensions | 60x60 mm |
| Top plate hole diameter | 6 mm |
| Dist. between holes | 46x46 mm |
| Load capacity | 60 kg |
Wheel
- solid rubber tyre blue-grey (Shore A 80)
- plastic wheel centre grey
- plain bearing
Technical description
- sheet steel metal housing
- swivel bearing with double ball race
- zinc passivated
Areas of application
- brochure display stands
- catering trolleys
- computer area
- computer furniture
- deep freezer
- display stands
- dustbins
- file carts
- food transport equipment
- housekeeping carts
- newspaper dispensers
- occasional carts
- photocopiers
- refrigerator
- restaurant areas
- sales stands
- shop fittings
- small furniture
- sport equipment
361a 33C075p ZPS
Swivel castor 75 mm, 100 kg
Technical data
| Diameter | 75 mm |
| Tread width | 2x23 mm |
| Height | 102 mm |
| Offset | 28,5 mm |
| Top plate dimensions | 55x70 mm |
| Top plate hole diameter | 5,5 mm |
| Dist. between holes | 51/57x41 mm |
| Load capacity | 100 kg |
Wheel
- solid rubber tyre blue-grey with profile (Shore A 80)
- plastic wheel centre grey
- metal thread guard zinc-passivated
- flange bearing
Technical description
- sheet steel metal housing
- with double ball race
- zinc passivated
Areas of application
- catering trolleys
- computer furniture
- dustbins
- file carts
- occasional carts
- housekeeping carts
- food transport equipment
- sport equipment
- sales stands
- laundry carts
- newspaper dispensers
- display stands
- restaurant areas
- brochure display stands
- deep freezer
- refrigerator
- small furniture
- photocopiers
- shop fittings
361a 34C075v GPS
Swivel castor 75 mm, 100 kg
Technical data
| Diameter | 75 mm |
| Tread width | 2x23 mm |
| Height | 102 mm |
| Offset | 28,5 mm |
| Top plate dimensions | 55x70 mm |
| Top plate hole diameter | 5,5 mm |
| Dist. between holes | 51/57x41 mm |
| Load capacity | 100 kg |
Wheel
- polyurethane tyre iron grey RAL 7011 (Shore A 95)
- plastic wheel centre and plastic thread guard silver grey RAL 7001
- ball bearing
Technical description
- sheet steel metal housing
- with double ball race
- yellow chrome plated
Areas of application
- catering trolleys
- computer furniture
- dustbins
- file carts
- occasional carts
- housekeeping carts
- food transport equipment
- sport equipment
- sales stands
- laundry carts
- newspaper dispensers
- display stands
- restaurant areas
- brochure display stands
- deep freezer
- refrigerator
- small furniture
- photocopiers
- shop fittings
361b 33C075p ZPS
Swivel castor with wheel locking brake 75 mm, 100 kg
Technical data
| Diameter | 75 mm |
| Tread width | 2x23 mm |
| Height | 102 mm |
| Offset | 28,5 mm |
| Top plate dimensions | 55x70 mm |
| Top plate hole diameter | 5,5 mm |
| Dist. between holes | 51/57x41 mm |
| Load capacity | 100 kg |
Wheel
- solid rubber tyre blue-grey with profile (Shore A 80)
- plastic wheel centre grey
- metal thread guard zinc-passivated
- flange bearing
Technical description
- sheet steel metal housing
- with double ball race
- zinc passivated
Areas of application
- catering trolleys
- computer furniture
- dustbins
- file carts
- occasional carts
- housekeeping carts
- food transport equipment
- sport equipment
- sales stands
- laundry carts
- newspaper dispensers
- display stands
- restaurant areas
- brochure display stands
- deep freezer
- refrigerator
- small furniture
- photocopiers
- shop fittings
361b 34C075v GPS
Swivel castor with wheel locking brake 75 mm, 100 kg
Technical data
| Diameter | 75 mm |
| Tread width | 2x23 mm |
| Height | 102 mm |
| Offset | 28,5 mm |
| Top plate dimensions | 55x70 mm |
| Top plate hole diameter | 5,5 mm |
| Dist. between holes | 51/57x41 mm |
| Load capacity | 100 kg |
| Weight | 655 g |
Wheel
- polyurethane tyre iron grey RAL 7011 (Shore A 95)
- plastic wheel centre and plastic thread guard silver grey RAL 7001
- ball bearing
Technical description
- sheet steel metal housing
- with double ball race
- yellow chrome plated
Areas of application
- catering trolleys
- computer furniture
- dustbins
- file carts
- occasional carts
- housekeeping carts
- food transport equipment
- sport equipment
- sales stands
- laundry carts
- newspaper dispensers
- display stands
- restaurant areas
- brochure display stands
- deep freezer
- refrigerator
- small furniture
- photocopiers
- shop fittings
364a 29G100r ZPF
Fixed castor 100 mm - 125 mm, 100 kg
Technical data
| Diameter | 100 mm |
| Tread width | 30 mm |
| Height | 138 mm |
| Top plate dimensions | 95x70 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 75x45/72x52 mm |
| Load capacity | 100 kg |
Wheel
- thermoplastic elastomer tyre (TPE) iron grey RAL 7011 (Shore A 80)
- plastic wheel centre silver grey RAL7001
- without thread guard
- plain bearing
- Contact discoloration on unsealed grounds possible!>>
Technical description
- sheet steel metal housing
- zinc passivated
Areas of application
- brochure display stands
- care beds
- cleaning equipment
- computer area
- display stands
- dustbins
- file carts
- food transport equipment
- housekeeping carts
- industrial kitchens
- laundry carts
- medical equipment
- newspaper dispensers
- occasional carts
- restaurant areas
- sales stands
- shop fittings
- sport equipment
- tripods
