Stainless Steel Castors
In the age of high technology the latest hygiene regulations shape the climate in laboratories for biotechnology, medicine and food research. Cleanliness is an essential part of quality management. Stainless steel castors from RHOMBUS are dazzling with their outstanding properties for this kind of environment. Produced from high-quality pure steel and precisely manufactured, they bring sterilising and instrument cabinets and other mobile units safe and clean to their destination.
JXPG 0802 6123/B
Swivel castor with wheel locking brake 80 mm - 200 mm, 50 kg - 270 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 25 mm |
| Hub length | 45 mm |
| Height | 110 mm |
| Offset | 35 mm |
| Wheel axle diameter | 12 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 120 mm |
| Load capacity | 50 kg |
| Weight | 1.2 kg |
Wheel
- Polyamide wheel with grey rubber tyre
- (Shore A 85) and two deep groove ball bearings
Technical description
- Swivel fork of deep drawn stainless steel with wheel brake.
- Swivelhead with sealed precision ball bearing, grease nippel
- and O-ring seal. In case of extreme conditions
- (like frequent jet cleaning) maintenance by relubrication
- is necessary
JXPG 0805 1000
Swivel castor 80 mm - 125 mm, 50 kg - 100 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 25 mm |
| Hub length | 40 mm |
| Height | 106 mm |
| Offset | 33 mm |
| Wheel axle diameter | 12 mm |
| Bolt hole diameter | 12.5 mm |
| Brake swivel radius | 135 mm |
| Load capacity | 50 kg |
| Weight | 0.6 kg |
Wheel
- Polypropyleene wheel with grey rubber tyre (Shore A 85) and plain bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race
JXPN 0801 1100
Swivel castor 80 mm - 200 mm, 200 kg - 250 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 30 mm |
| Hub length | 40 mm |
| Height | 106 mm |
| Offset | 33 mm |
| Wheel axle diameter | 12 mm |
| Top plate dimensions | 105 x 80 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 135 mm |
| Load capacity | 200 kg |
| Weight | 0.7 kg |
Wheel
- Polyamide wheel with plain bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race
JXPN 0801 5100
Swivel castor 80 mm - 125 mm, 175 kg - 200 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 30 mm |
| Hub length | 42 mm |
| Height | 105 mm |
| Offset | 38 mm |
| Bolt hole diameter | 12 mm |
| Brake swivel radius | 113 mm |
| Load capacity | 175 kg |
| Weight | 0.73 kg |
Wheel
- Polyamide wheel with one sealed deep groove ball bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race
JXPN 0801 7100
Swivel castor 80 mm - 125 mm, 175 kg - 150 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 35 mm |
| Hub length | 45 mm |
| Height | 105 mm |
| Offset | 38 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9.6 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 113 mm |
| Load capacity | 175 kg |
| Weight | 0.9 kg |
Wheel
- Polyamide wheel with one sealed stainless steel
- deep groove ball bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race
JXPN 0802 5000
Swivel castor 80 mm - 125 mm, 175 kg - 250 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 30 mm |
| Hub length | 45 mm |
| Height | 110 mm |
| Offset | 35 mm |
| Wheel axle diameter | 8 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 120 mm |
| Load capacity | 175 kg |
| Weight | 0.9 kg |
Wheel
- Polyamide wheel with one sealed deep groove ball bearing
Technical description
- Swivel fork of deep drawn stainless steel. Swivelhead with
- sealed precision ball bearing, grease nippel and O-ring seal.
- In case of extreme conditions (like frequent jet cleaning) maintenance
- by relubrication is necessary
JXPN 0802 5000/B
Swivel castor with wheel locking brake 80 mm - 125 mm, 175 kg - 250 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 30 mm |
| Hub length | 45 mm |
| Height | 110 mm |
| Offset | 35 mm |
| Wheel axle diameter | 8 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 120 mm |
| Load capacity | 175 kg |
| Weight | 1.1 kg |
Wheel
- Polyamide wheel with one sealed deep groove ball bearing
Technical description
- Swivel fork of deep drawn stainless steel with wheel brake.
- Swivelhead with sealed precision ball bearing, grease nippel
- and O-ring seal. In case of extreme conditions
- (like frequent jet cleaning) maintenance by relubrication
- is necessary
JXPN 0802 7000
Swivel castor 80 mm - 125 mm, 175 kg - 250 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 35 mm |
| Hub length | 45 mm |
| Height | 105 mm |
| Offset | 35 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 120 mm |
| Load capacity | 175 kg |
| Weight | 0.9 kg |
Wheel
- Polyamide wheel with one sealed stainless steel
- deep groove ball bearing
Technical description
- Swivel fork of deep drawn stainless steel. Swivelhead with
- sealed precision ball bearing, grease nippel and O-ring seal.
- In case of extreme conditions (like frequent jet cleaning) maintenance
- by relubrication is necessary
JXPN 0802 7000/B
Swivel castor with wheel locking brake 80 mm - 125 mm, 175 kg - 250 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 35 mm |
| Hub length | 45 mm |
| Height | 105 mm |
| Offset | 35 mm |
| Top plate dimensions | 105 x 85 mm |
| Top plate hole diameter | 9 mm |
| Dist. between holes | 80 x 60 mm |
| Brake swivel radius | 120 mm |
| Load capacity | 175 kg |
| Weight | 1.1 kg |
Wheel
- Polyamide wheel with one sealed stainless steel
- deep groove ball bearing
Technical description
- Swivel fork of deep drawn stainless steel with wheel brake.
- Swivelhead with sealed precision ball bearing, grease nippel
- and O-ring seal. In case of extreme conditions
- (like frequent jet cleaning) maintenance by relubrication
- is necessary
JXPN 0805 1000
Swivel castor 80 mm - 125 mm, 200 kg
Technical data
| Diameter | 80 mm |
| Wheel width | 30 mm |
| Hub length | 40 mm |
| Height | 106 mm |
| Offset | 33 mm |
| Wheel axle diameter | 12 mm |
| Bolt hole diameter | 12.5 mm |
| Brake swivel radius | 135 mm |
| Load capacity | 200 kg |
| Weight | 0.547 kg |
Wheel
- Polyamide wheel with plain bearing
Technical description
- Swivel fork of deep drawn stainless steel
- Swivel bearing with double ball race
