Stainless Steel Castors
In the age of high technology the latest hygiene regulations shape the climate in laboratories for biotechnology, medicine and food research. Cleanliness is an essential part of quality management. Stainless steel castors from RHOMBUS are dazzling with their outstanding properties for this kind of environment. Produced from high-quality pure steel and precisely manufactured, they bring sterilising and instrument cabinets and other mobile units safe and clean to their destination.
FXPU 1253 6443
Fixed castor 100 mm - 200 mm, 180 kg - 515 kg
Technical data
Diameter | 125 mm |
Wheel width | 50 mm |
Hub length | 64 mm |
Height | 160 mm |
Offset | 50 mm |
Wheel axle diameter | 20 mm |
Top plate dimensions | 135 x 112 mm |
Top plate hole diameter | 11 mm |
Dist. between holes | 105 x 75,80 mm |
Brake swivel radius | 145 mm |
Load capacity | 320 kg |
Weight | 1.4 kg |


Wheel
- Polyamide wheel with polyurethane tyre
- (Shore A 96) with two deep groove ball bearings
Technical description
- Rigid fork of stainless steel
