The composition of the tyre and the various types of wheel rims or hubs as well as various wheel bearings give the wheel many different properties. Because of this wheels have differing load capacities, resistance to rolling and operational qualities.
BTAB 1253 6150
Swivel castor with total brake mounted behind 100 mm - 250 mm, 180 kg - 450 kg
Technical data
| Diameter | 125 mm |
| Wheel width | 50 mm |
| Hub length | 62 mm |
| Height | 155 mm |
| Offset | 42.5 mm |
| Top plate dimensions | 135 x 110 mm |
| Top plate hole diameter | 11 mm |
| Dist. between holes | 105 x 75/80 mm |
| Brake swivel radius | 134 mm |
| Load capacity | 200 kg |
| Weight | 3.2 kg |
Wheel
- Aluminium wheels with black rubber tyre (Shore A 72) with two deep groove ball bearings and steel collar bushes external diameter 15/20/25 mm to internal 8/10/12 mm. Operating temperatures from -20°C to + 80°C
Technical description
- Swivel fork of deep drawn zinc-coated steel
- Swivel bearing with double ball raceways and sealring
- with total lock brake and an extra sturdy
- plate (4 mm) and fork legs (3.5 mm)
- for even higher load capacity
